Baofeng DM-X
Baofeng DM-X walkie talkie without GPS. This walkie-talkie has DMR digital technology. It is a recently launched model.
Extra 3% discount when paying with Bitcoin or Ethereum.
(editar con el módulo de Información de seguridad y confianza para el cliente)
(editar con el módulo de Información de seguridad y confianza para el cliente)
(editar con el módulo de Información de seguridad y confianza para el cliente)
Specifications:
General
Frequency range: VHF: 136-174 MHz UHF: 400-470 MHz (dual band).
Memory channel: 1024
Operating voltage: DC 7.4 V
Stability in frequency: ±1! 0ppm
Emission: 136*62*36mm (without antenna).
Environment: -30℃-+ 60℃
Weight of the device: approaching.274g (including battery and antenna)
Transmitter
Output power: High: 5W Low: 1W
Power of adjacent channel: Proudly Presents.
Consumption at output Analog≤1=- proudly presents 6A Digital≤0! 9A
From the response + 1 ~ 3dB
Waiting time for current consumption ≤0 ! 18A
Digital protocol ETSI-TS102 361-1-2-3.
Distortion during modulation: ≤5%.
Type of vocoder: AMBE + 2 TM
FM/ FM modulation: 16K￠F3E 25 KHz 141K￠F3E 20 KHz 11K￠F3E 12.5 KHz.
Digital modulation 4FSK/4FSK: 12.5 KHz for data: 7K60FXD 12.5 KHz for data and voice: 7K60FXE.
Signal to noise (wide/narrow): ≥45dB 25 KHz ≥40dB 12.5 KHz
Wrong antenna connection: 9 KHz-1 GHz ≤-36dBm 1 GHz-12.75 GHz: ≤-30dBm.
Receiver
Analog receive sensitivity: -12dBm (12dB SINAD).
Digital receive sensitivity: -122dBm (BER≤5%).
Audio power: 1W
Audio distortion: <10%.
Imitation signal: ≥70dB
From response: + 1 ~ 3dB
Receive current: ≤380mA
Particle noise: ≥45dB 25 KHz/≥40dB 12.5 KHz
Package includes:
1× BAOFENG DM-X
1 × 2200 mAh Li-ion battery pack
1 × EU plug
1× antenna
1× wrist strap
1× belt clip
1× headphones
1× user manual
